PowMr 10KW Split Phase Inverter 48V 110V 220V Hybrid Solar Inverter Dual MPPT Dual Output Off Grid with MPPT 200A Solar Charger
PowMr 10KW Split Phase Inverter 48V 110V 220V Hybrid Solar Inverter Dual MPPT Dual Output Off Grid with MPPT 200A Solar Charger
Couldn't load pickup availability
SPECIFICATIONS
Battery Type: Lithium-ion, lead-acid battery
Brand Name: PowMr
Certification: CE
Communication Interfaces: RS485/CAN/USB/Dry contact
High-concerned chemical: None
Is Smart Device: Yes
Max AC Charging Current: MPPT 120A
Max PV Charging Current: MPPT 200A
Max PV array power: 11,000W
Max Peak Power: 20KW
Max Voltage of Open Circuit: 500Vdc
Model Number: POW-SunSmart 10K
Origin: Mainland China
Output Current: MPPT 200A
Output Frequency: 50Hz/60Hz
Output Power: 1 - 200 KW
Output Type: DUAL
Rated Output Voltage: 120 or 240Vac
Size: 620*435*130mm
Type: Off Grid Inverter
Warranty: 1 Year
Weight: 26KG
is_customized: Yes
PowMr 10KW Split Phase Inverter 48V 110V 220V Hybrid Solar Inverter Dual MPPT Dual Output Off Grid with MPPT 200A Solar Charger
|
MODEL |
POW-SunSmart8K |
POW-SunSmart10K |
CANBESET |
INVERTER OUTPUT | |||
Rated Output Power |
8,000W |
10,000W |
|
Max. Peak Power |
16,000W |
20,000W |
|
Rated Output Voltage |
120/240Vac（split phase/single phase） |
Y |
|
Load Capacity ofMotors |
5HP |
6HP |
|
Rated AC Frequency |
50/60Hz |
Y |
|
Wave form |
Pure Sine Wave |
||
Switch Time |
10ms（typical） |
||
Parallel capacity |
/ |
||
|
Overload |
After triggering the overload protection the inverter willresume output after 3 minutes, 5 consecutiveoverloads will switch off the output until the inverter isrestarted. (102%<load<110%) ±10%: error and output shutdownafter5min; (110% < load < 125%) ±10%: error and output shutdown after 10s. Load>125%±10%:errorreportedand output switchedoffafter5s. |
||
BATTERY | |||
Battery Type |
Li-ion/ Lead-Acid/User Defined |
Y |
|
Rated Battery Voltage |
48Vdc |
||
Voltage Range |
40-60Vdc |
Y |
|
Max. MPPT Charging Current |
200A |
Y |
|
|
Max. Mains/Generator Charging Current |
100A |
120A |
Y |
Max. Hybrid Charging Current |
180A |
200A |
Y |
PV INPUT | ||
Num. of MPPTrackers |
2 |
|
Max. PV array power |
11,000W |
|
Max. input current |
22/22A |
|
Max. Voltage of Open Circuit |
500Vdc |
|
MPPT Voltage Range |
125-425Vdc |
|
MAINS/ GENERATOR INPUT | ||
Input Voltage Range |
90-140Vac |
|
Frequency Range |
50/60Hz |
|
Bypass Overload Current |
63A |
|
EFFICIENCY | ||
MPPT Tracking Efficiency |
99.9% |
|
Max. Battery Inverter Efficiency |
92% |
|
GENERAL | ||
Dimensions |
620*445*130mm（2*1.5*0.4ft） |
|
Weight |
27kg（59.5lb） |
|
Protection Degree |
IP20，Indoor Only |
|
|
Operating Temperature Range |
-10~55℃,>45℃derated （14~131℉，>113℉derated） |
|
Noise |
<60dB |
|
Cooling Method |
Internal Fan |
|
Warranty |
2Years |
|
COMMUNICATION | ||
Embedded Interfaces |
RS485/CAN/USB/ Dry contact |
Y |
External Modules（Optional） |
Wi-Fi /GPRS |
Y |
CERTIFICATION | ||
Safety |
IEC62109-1,IEC62109-2,UL1741 |
|
EMC |
EN61000-6-1,EN61000-6-3, FCC15classB |
|
RoHS |
Yes |
|
Feacture:
* Pure Sine Wave inverter.
* Higher output power up to 10000W.
