ANNKE 4K Ultra HD POE Video Surveillance System 8CH NVR Recorder With 8MP Security Cameras CCTV Kit Audio Recording 4K Ip camera

$449.99 USD

~~$0.00 USD~~ $449.99 USD

Sale Sold out

Shipping calculated at checkout.

Ships From United States

Build-in HDD None

SPECIFICATIONS

Brand Name: ANNKE

Cable Length: 30m,18m

Certification: CE,FCC

High-concerned chemical: None

Model Number: N48PAW-I91DM

Origin: Mainland China

PCS of Camera: 4PCS

Resolution: 8MP

Smart home platform: Other

TV System: NTSC,PAL

Video Input: 8 Channel

8MP IP Camera Key features:

★ 4K smart dual light turret network camera

★ 4mm@F1.6 lens brings everything back to life

★ Efficient H.265+ compression technology

★ Motion detection 2.0 with human & Vehicle Detection

★ Clear day and night vision with 3D DNR and 120DB WDR

★ Built-in microphone for real-time audio security

★ Support on-board storage up to 512 GB (SD card slot)

★ IP67 Dust and Waterproof Rating

★ Support PoE &DC12V

NVR Key features:

· 8MP high definition Real-time live viewing

· Live view, recording&playback up to 8 MP resolution

· Up to 8 channel IP cameras can be connected with built-in PoE inputs· Advanced H.265+ Video Compression

· Supports iPhone、iPad、Android mobile remote monitoring

· Connectable to the third-party network cameras

· HDMI Video output at up to 4K (3840 × 2160) resolution

· Annke Vision for easy remote view

[Intelligent dual light]

Smart Dual-Light: advanced technology with long range, IR light works normally at night, and it switches to white light when human or vehicle are detected.

[120 dB True WDR & 3D DNR]

True WDR can be used in various scenes, whether it is backlight or backlight, you can see clearly;

BLC/3D DNR/HLC image enhancement technology, the image is cleaner and the night vision is clearer

[More Videos & Less Bandwidth with H.265+]

The leading H.265+ compress tech enables the 4K system to record longer videos & consume less bandwidth without losing 4K quality, saving you up to 80% storage space

Hi-Fi Audio Recording

The built-in noise-cancelling mic picks up the ambient voice clearly from up to 20 ft away, enhancing the security coverage & the ability to interpret motion events.

[Support Home Assistant & Apple HomeKit]

Besides free ANNKE Vision App for remote access, you may integrate the system to third-party platforms, like Blue Iris, Synology, Milestone, Home Assistant, Apple HomeKit, etc.

24/7 Monitoring at Every Angle

The versatile PoE security camera system records videos continuously, providing true 24/7 all-around protection for your home, office, garage, supermarket, etc.

Remote Access and Smart Motion Alerts

Access & control the system remotely with free ANNKE software via 3G/4G/5G or WiFi on your smartphone, tablet or computer when you are in the office or traveling. Get instant app pushes & email alerts with snapshots when there are motion events.

Customized Motion Areas

Customize the specific motion zones, like garage, front door, etc. for much more relevant motion alerts.

Outdoor IP67 Weatherproof

with IP67 weatherproof rating, the Ethernet camera braves anything, from torrential downpours to freezing/broiling temperatures (-22 °F – 140 °F), perfect for both outdoor & indoor installation. The solid housing provides fast heat dissipation & corrosion resistance.

Easy Plug and Play PoE Installation

Connect the camera to the PoE NVR with just a network cable for both data & power transmission. The expandable NVR supports up to 8 ANNKE & third-party ONVIF PoE cameras (up to 4K) for all-angle coverage. Record videos 24/7 even without Internet.

NVR
Video & Audio	Video Compression	H.264+/H.264/H.265/H.265+
	IP Video Input	8CH PoE
	Video Output	HDMI up to 4K, VGA up to 1080p
	Audio Input/Output	1/1 RCA
	Incoming/outgoing Bandwidth	80/80 M
	Max Recording Resolution	Up to 8MP (3840 X 2160)@30fps(Frame rate depends on IP camera)
	Max Playback Resolution	Up to 8MP (3840 X 2160)@30fps(Frame rate depends on IP camera)
	Max Playback Channel	8CH
	Max Playback Capacity	1-ch@8 MP (30 fps)/5-ch@1080p (30 fps)
	ONVIF Protocols	Support
Hard Drive	HDD	1 SATA Interface
Hard Drive	HDD Capacity	Up to 8 TB Capacity
External Interface	Network Interface	1, RJ-45 10/100Mbps self-adaptive Ethernet interface
	PoE	8, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at
	USB interface	USB 2.0*2
Smart Function	Deep learning	Human and vehicle targets detection(Need IP camera support)
Smart Function	Smart Event	Line crossing detection, intrusion detection, region entrance detection, region exiting detection(Need IP camera support)
General	Operating Power	DC 48 V
	Power Consumption	≤10 W (Without HDD and PoE)
	Power Consumption	PoE: Max 25.5 W for Single Port
	Working Temperature	14 °F ~ 131 °F/-10 °C ~+55 °C
	Dimensions (W X H X D)	12.4” X 9.4” X 1.9”/315 X 240 X 48 mm
	Weight (Without Hard Disk)	2.2 lbs/1 kg

8MP IP Camera
Camera	Image Sensor	1/2.4" Progressive Scan CMOS
	Max resolution	3840*2160(8MP)
	Main Stream	50 Hz: 12.5fps@38402160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 15fps@38402160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
	Substream	50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
	Video Compression	Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
	Video Bitrate	32 Kbps - 16 Mbps
	Audio Compression	G.711/G.722.1/G.726/MP2L2/PCM/ AAC-LC
	Audio Input	Built-in Microphone, record with audio
	Lens	4 mm
	Min. Illumination	Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
	Angle of View	Horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°
	Supplement Light Type	Smart Dual-Light, IR, White Light
	Supplement Light Range	IR: up to 30 m, white Light: up to 20 m
	Motion detection 2.0	Supoort, include Human & Vehicle detection
	Image Enhancement	BLC, HLC, 3D DNR
	Wide Dynamic Range	120 dB WDR
	Protocols	TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
	API	Open Network Video Interface Version (Profile S, Profile T, Profile G)
	Region of Interest (ROI)	1 fixed region for main stream
	Privacy Mask	4 programmable polygon privacy masks
	General Function	Rotate mode, mirror, password protection, remote access
	Ethernet	1 RJ45 10 M/100 M self-adaptive Ethernet port
General	Housing	Metal & Plastic
	Color	White
	Storage	Built-in microSD/SDHC/SDXC Slot, up to 512 GB
	Hardware Reset	Yes
	Operating Power	DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W
	Operating Temperature	-22 °F – 140 °F/-30 °C – 60 °C
	Indoor/Outdoor Use	Indoor/Outdoor
	Interface Protection	IP67
	Dimension (L X W X H)	Ø110 mm × 89.2 mm (Ø4.3" × 3.5")
	Weight	0.7 lb./340 g

Dual-light camera: three lighting modes to choose from

1. Intelligent mode: By default, the infrared light turns on at night and the picture is black and white. When someone and a car trigger it, the infrared light goes out and the white light turns on to turn into a color picture.

2. Infrared mode: infrared fill light 30 meters.

3. White light mode: white light fill light 20 meters.
